Standard ANSI/BHMA A156.17-2014 establishes requirements for Self Closing Hinges & Pivots. In 5.3.1 cycle requirements, it clearly states different grades of single acting hinges. Although the spec says we should not use this test procedure as a guide for actual installations, it still provides valuable quality assurance for hinge standard.
| Single Acting Hinges | |
| *Cycles | Number |
| Grade 1 | 1,000,000 |
| Grade 2 | 500,000 |
| Grade 3 | 250,000 |
*Cycle requirement on BHMA A156.17 Standard
Best Single Acting Hinges
Waterson 3 in 1 Grade 1 Closer Hinges combine the functionality of 1) a door closer, 2) a heavy-duty hinge, and 3) an optional door hold-open. This is a money-saving product because it eliminates the expense of purchasing and installing an overhead door closer and hold-open plus all the extra costs associated with preparing a door and frame for overhead hardware devices.
Waterson door closer hinge also reduces ongoing maintenance costs. In order to assure long service life and dependability, they have been tested with ANSI/BHMA A156.17 to withstand over 1,000,000 cycles (Grade 1). The patented mechanical-hydraulic action makes Waterson Hinges simple to adjust securely and quietly. Moreover, Waterson Closer Hinges are not subject to the abuse or damage that plagues the projecting arms of overhead closers.
Aside from saving money, Waterson Hinges provide these unique benefits to the door hardware industry.
- Improve the aesthetics of doors by avoiding the need for unattractive overhead door closers and hold opens.
- Install in locations that are incompatible with overhead closers.
- Fit standard hinge templates for easy installation.
- Meets UL-list for use on doors with up to three-hour fire resistance.
- Are available in stainless steel or aluminum, plus a variety of finishes.
- Offers in sizes and configurations suitable for a wide range of wood and metal commercial and residential doors, glass doors, and gates.
- Are fully adjustable to comply with ADA opening requirements and to close securely and quietly.
Waterson Stainless Steel BHMA A156.17 Door Hinges
Waterson Hinges combine an overhead closer and hinge into one attractive component with optional hold-open and door stop features. These hinges are ideal for commercial openings, gates, and glass doors. The hinges are easily installed and adjusted to comply with ADA & ICC A117.1 requirements for opening force and to assure quiet, secure closing. Made with stainless steel, Waterson closer hinges meet NFPA 80 and are UL 3-hour fire-rated, as well as being suitable for both interior and all-weather exterior openings. See all our features.
Request For Information
Please note that Waterson Closer Hinges start from a size of 4″x4″. If you’re in need of smaller self-closing hinges, we’d recommend checking out some other resources! Also, we only provide single acting closer hinges. Thank you.
