When choosing gate hardware, durability and functionality are key factors. While D&D TruClose Gate Hinge is an ideal option for exterior gate applications, a side-by-side with Waterson Heavy Duty Gate Hinge reveals several interesting highlights.

TruClose Gate Hinges Overview

D&D Technologies is known for producing high-quality gate latches, locks, and self-closing gate hinges, as well as hydraulic gate closers. They operate under the ASSA ABLOY brand, and one of their more popular products is the TruClose Gate Hinges.

Waterson Gate Hinges Overview

Waterson Gate Hinges, on the other hand, are family-owned and operated. These hinges also provides high-quality and durable spring gate hinges in addition to ones that feature both purely mechanical (no hydraulic, worry-free from oil change) as well as mechanical-hydraulic hybrid.

truclose gate hinges and waterson gate hinges

Materially Speaking

D&D TruClose gate hinges and Waterson gate hinges share some similarities; however, they diverge in other respects. For example, both hinges provide self-closing functionality, can be used on metal and wood gates, and can easily be installed by one person. That said, while TruClose gate hinges are only available in black and white finishes, Waterson gate hinges are available in many more options. At the same time, TruClose gate hinges are made with polymer material, whereas Waterson gate hinges are produced with heavy-duty stainless steel.

For more comparison information, see the table below.

Features Waterson Surface Mount Gate Hinges TruClose Regular Duty Adjustable Hinges TruClose Heavy Duty Hinges
Model K51P TCAMA2 TCHD1L2S3BTS
Self-Closing  Max
2 hinges 150 lbs 55 lbs 154 lbs
3 hinges 260 lbs NA NA
4 hinges 330 lbs NA NA
Material Stainless Steel 304 & 316 Plastic Polymer Plastic Polymer
Gate Type
Metal < 260 lbs < 55 lbs < 154 lbs
Wood < 260 lbs < 55 lbs < 154 lbs
Vinyl Not Available < 55 lbs < 154 lbs
Gate Post 1”-4”, Square Post 2” max, Square Post
Self-closing Yes Yes Yes
Weather Resistance Corrosion Resistant UV Resistant UV Resistant
Test Standard UL* Not Provided AS1926-12
Closing Mechanism

– Mechanical

– Hydraulic

Hydraulic Hydraulic
Origin Taiwan Australia Australia
Warranty

– Mechanical 10yrs

– Hydraulic 5yrs

Not provided Lifetime Warranty
Finish Color

Stainless Steel Black. Satin Brass, Dark Bronze, Satin Bronze, custom available

Black and White Black and White

*Self-closing mechanism is UL certified

If you intend to learn more about Waterson’s offering on gate hinge line, this Gate Hinges Heavy Duty Stainless Steel with Self Closing Page could greatly support your needs.

Request For Quote

Please note that Waterson closer hinges start from a size of 4″x4″. If you’re in need of smaller self-closing hinges, we’d recommend checking out some other resources! Also, we only provide single acting closer hinges. Thank you.
