When choosing gate hardware, durability and functionality are key factors. While D&D TruClose Gate Hinge is an ideal option for exterior gate applications, a side-by-side with Waterson Heavy Duty Gate Hinge reveals several interesting highlights.
TruClose Gate Hinges Overview
D&D Technologies is known for producing high-quality gate latches, locks, and self-closing gate hinges, as well as hydraulic gate closers. They operate under the ASSA ABLOY brand, and one of their more popular products is the TruClose Gate Hinges.
Waterson Gate Hinges Overview
Waterson Gate Hinges, on the other hand, are family-owned and operated. These hinges also provides high-quality and durable spring gate hinges in addition to ones that feature both purely mechanical (no hydraulic, worry-free from oil change) as well as mechanical-hydraulic hybrid.
Materially Speaking
D&D TruClose gate hinges and Waterson gate hinges share some similarities; however, they diverge in other respects. For example, both hinges provide self-closing functionality, can be used on metal and wood gates, and can easily be installed by one person. That said, while TruClose gate hinges are only available in black and white finishes, Waterson gate hinges are available in many more options. At the same time, TruClose gate hinges are made with polymer material, whereas Waterson gate hinges are produced with heavy-duty stainless steel.
For more comparison information, see the table below.
| Features | Waterson Surface Mount Gate Hinges | TruClose Regular Duty Adjustable Hinges | TruClose Heavy Duty Hinges |
|---|---|---|---|
| Model | K51P | TCAMA2 | TCHD1L2S3BTS |
| Self-Closing Max | |||
| 2 hinges | 150 lbs | 55 lbs | 154 lbs |
| 3 hinges | 260 lbs | NA | NA |
| 4 hinges | 330 lbs | NA | NA |
| Material | Stainless Steel 304 & 316 | Plastic Polymer | Plastic Polymer |
| Gate Type | |||
| Metal | < 260 lbs | < 55 lbs | < 154 lbs |
| Wood | < 260 lbs | < 55 lbs | < 154 lbs |
| Vinyl | Not Available | < 55 lbs | < 154 lbs |
| Gate Post | 1”-4”, Square Post | 2” max, Square Post | |
| Self-closing | Yes | Yes | Yes |
| Weather Resistance | Corrosion Resistant | UV Resistant | UV Resistant |
| Test Standard | UL* | Not Provided | AS1926-12 |
| Closing Mechanism |
– Mechanical – Hydraulic |
Hydraulic | Hydraulic |
| Origin | Taiwan | Australia | Australia |
| Warranty |
– Mechanical 10yrs – Hydraulic 5yrs |
Not provided | Lifetime Warranty |
| Finish Color |
Stainless Steel Black. Satin Brass, Dark Bronze, Satin Bronze, custom available |
Black and White | Black and White |
*Self-closing mechanism is UL certified
If you intend to learn more about Waterson’s offering on gate hinge line, this Gate Hinges Heavy Duty Stainless Steel with Self Closing Page could greatly support your needs.
Request For Quote
Please note that Waterson closer hinges start from a size of 4″x4″. If you’re in need of smaller self-closing hinges, we’d recommend checking out some other resources! Also, we only provide single acting closer hinges. Thank you.
