Why are spring-loaded door hinges challenged by itself?

Spring-loaded door hinges are significantly smaller than door closer/floor spring. Unfortunately, the smaller size means the downsized capacity. There is simply no ample space to squeeze in all the closing mechanism in the hinge. So most spring hinges on the market are, namely, spring-loaded hinges without much adjustability.
With simple spring mechanisms hidden inside, these hinges are prone to spring failure/fatigue, slamming, and consequently fast replacement. These fragile spring hinges have caused great inconvenience mentally and financially for end-users and business owners. This is also why some renowned hotels are replacing spring hinges to a new type of self closing hinge.

Read more : Why Five Star Hotel Replace existing Spring hinge to Waterson in just 2 years?

Buyers be aware: the life-saving codes of compliance

Code of practice and regulations are established to ensure the overall quality of spring-loaded door hinges:

  • The assurance of one million cycles:
    ANSI A156.17 ANSI A156.17: SELF CLOSING HINGES & PIVOTS

This standard contains requirements for cycle test, finish/material, and dimensions.
Notably, the cycle test for the Grade 1 hinges is 1,000,000 times. Buyers can confidently purchase spring hinges with the Grade 1 certificate without worrying the frequent replacement and untrusted reliability.

spring loaded door hinge-2

Attention! The door or gate shall move to the closed position in 1.5 seconds minimum!

  • ADA 404.2.8.2

“Spring Hinges. Door and gate spring hinges shall be adjusted so that from the open position of 70 degrees, the door or gate shall move to the closed position in 1.5 seconds minimum.”
This code ensures the safety of all users, physically challenged or not, because slower door closing speed creates a hassle and risk-free door entry.

  • California Building Code 2016 (1126A.4.2 Spring hinges)

“Spring hinges shall be adjusted so that from the open position of 70 degrees, the door or gate shall move to the closed position in 1.5 seconds minimum.”
Here we see the uncontrollable speed of spring-loaded door hinges is being scrutinized and action is taken: the minimum closing time is again 1.5 seconds.
In public premises like public libraries, most times the door closing speed is too fast, and the uncontrollable door would hit older users on their backside. This is not a simple matter of annoyance; this is, in fact, a matter that should be treated as a public health issue.

In the UK, spring hinges are prohibited from application on fire door due to the uncontrollable speed. Here are some interesting codes:

  • 2.2.6, Code of Practice: Hardware for Fire and Escape Doors(UK):

Here the code of practice rules out the competence of spring hinge for fire safety:
“Spring hinges are NOT recommended for use on fire-resisting doors.”

  • 3.2.7, Code of Practice: Hardware for Fire and Escape Doors(UK):

This code points out that poor adjustability is the reason why the spring hinge is not suitable for safety-related applications like fire door.
However, a new generation of “self-closing hinge” can perfectly fit fire-rated door with flexible adjustability. Famous businesses like KFC (Kentucky Fried Chicken) even use these self-closing hinges on their fire doors.

See story : The New Door Closing Hinge Adopted by KFC

“Spring hinges, which are purely spring urged and do not control the
closing speed, are unable to comply with BS EN 1154 and therefore
should NOT be used for fire doors.

  • 3.3.8, Code of Practice: Hardware for Fire and Escape Doors(UK):

In addition to the absence of adjustability, the weak closing power also makes spring loaded door hinges utterly unfitting hardware for safety concern:
“These uncontrolled closers do not meet the requirements in Approved
Document B 2006 edition for self-closing devices (see 3.1 Introduction
for details)……On unlatched doors, they are unlikely to hold the door leaf closed
against the pressures are known to exist in fire situations until any heat-activated sealing system has operated. ”

A New breed of spring-loaded door hinges

A new type of spring-loaded door hinge is booming. These new spring hinges are often referred to as “self-closing hinge” or “door closer hinge” with much greater capacity, flexible adjustability, and way higher durability. The Waterson Self closing hinge is one of the examples:

1.Fire-resistant: 3hrs fire rating
2.Adjustability: 7-speed adjustable
3.Durability: 1 Million cycles per ANSI A156.17, grade 1
4.Loading: from 10 to 200 KG
5.Barrier-free: ADA compliant; easy entry for all users
