Project Description

Recently, Waterson addressed a special challenge when a client reported issues and wanted to install our heavy-duty 4.5″ hydraulic door closers with Wilson aluminum jambs. The main issue stemmed from the larger barrel size of the old closers, which did not align well with the jambs’ flush casing. This resulted in the hinge leaves not fitting properly, complicating the installation and affecting door functionality.

Waterson hydraulic door closers



Solution Implemented

To address the specific installation challenges, Waterson responded with a customized hydraulic door closers, specifically designed with a 4.5” x 5” dimension. This customization ensured compatibility with the aluminum jambs, resolving the initial issue where the flush casing prevented the door closer leaves from fitting properly. The door closer adjustments made to the closer leaf allowed it to adapt to the jamb structure fully, ensuring a seamless installation.

Hydraulic Door Closer Exceptional Features

Waterson hydraulic door closer incorporates several exceptional features to enhance door functionality and user experience:

  • Door Stop Mechanism: Prevents wall damage by controlling the door swing.
  • Hold Open: Allowing doors to remain open as needed.
  • Fire-rated: Meet NFPA 80 and are UL 3-hour fire-rated.
  • Hydraulic Action Zone (HAZ): Equipped with a hydraulic mechanism that decelerates door closing speed within the final 30°, ensuring safety and quiet operation.
  • Adjustment Capabilities: Includes two key adjustments; a 3mm hex nut for speed reduction by increasing hydraulic oil engagement, and a 5mm hex nut for altering the active area of the HAZ. Learn more about hydraulic door closer speed adjustment here.
  • Buffering Feature: Provides further control over door closing speed, ideal for doors that open ≤ 120° and operate in environments above 32°F (0°C), thereby ensuring the longevity of the hinge mechanism.

For further information about Waterson K51M-455 Hydraulic Door Closers, click here.

hydraulic door closer

Waterson Heavy Duty Stainless Steel Hydraulic Door Closers

Waterson Closer Hinges combine an overhead closer and hinge into one attractive component with optional hold-open and door-stop features. Waterson hinges are ideal for commercial openings, gates, and glass doors. These closer hinges are easily installed and adjusted to comply with ADA & ICC A117.1 requirements for opening force and to assure quiet, secure closing. Made with stainless steel, Waterson closer hinges meet NFPA 80 and are UL 3-hour fire-rated, as well as being suitable for both interior and all-weather exterior openings. See all our features.
