ADA compliance in commercial bathrooms isn’t just about meeting regulations—it’s about creating spaces that welcome and empower everyone. Key standards across Florida, Texas, and California focus on practical accessibility features like door dimensions, operational ease, and wheelchair maneuverability. These ADA requirements ensure that all users can navigate facilities comfortably and dignity.

ADA commerical door hinges

The Florida Statutes | 553.504 – Exceptions to applicability of the federal standards

According to Chapter 553 Building Construction Standards, ADA bathroom requirements for commercial buildings are regulated in (2) (3) and (5a):

(2)…However, if only a toilet room is provided at grade level, such a toilet room must have a clear opening of at least 29 inches.

(3) Notwithstanding the requirements in s. 404.2.9 of the standards, exterior hinged doors must be designed so that such doors can be pushed or pulled open with force not exceeding 8.5-foot pounds.

(5) Notwithstanding ss. 213 and 604 of the standards, required bathing rooms and toilet rooms in new construction shall be designed and constructed in accordance with the following:

(a) The wheelchair-accessible toilet compartment must contain an accessible lavatory within it, which must be at least 19 inches wide by 17 inches deep, nominal size, and wall-mounted. The lavatory shall be mounted so as not to overlap the clear floor space areas required by s. 604 of the standards for the wheelchair-accessible toilet compartment and comply with s. 606 of the standards. Such lavatories shall be counted as part of the required fixture count for the building. Go further with the ADA recessed door clearance here

Texas Accessibility Standards (TAS) | A4.2 Space Allowances and Reach Ranges

In the A4.2 section – Texas Accessibility Standards (TAS), the ADA door clearances are stated as follows:
A4.2.1(1): Doorways and passageways must have a minimum clear width of 32 inches, and if the restriction exceeds 24 inches in length, the passageway must be at least 36 inches wide.

A4.2.3: Bathrooms must provide a turning space of at least 60 inches in diameter or a T-shaped space measuring 60 inches by 60 inches for wheelchair users to pivot 180 degrees.

A4.2.4: Clear floor or ground space must accommodate the dimensions and maneuvering needs of most wheelchairs.

California Inspection Checklist Disable Access Regulations

Accordingly, the California Disable Access Regulations state that all entrances and exterior and interior exit doors regardless of the occupant load shall be made accessible to persons with disabilities.

  • ¾ Size = Min 3’-0” wide (32” clear when 90° open) and 6’-8” in height.
  • ¾ Door hardware = operable with a single effort without requiring the ability to grasp hardware.
  • ¾ Effort to operate doors = 8.5 pounds at exterior doors and 5 pounds at interior doors
  • ¾ Door hardware height = 30” – 44” above the floor.

Waterson hinge Swing Away Hinges

So What are the Key ADA Bathroom Requirements for Commercial Buildings?

Door Width: Minimum clear opening: 32 inches (Texas, California); 29 inches for certain Florida cases.

Operational Force: 5 lbs, Max 8.5 lbs (Florida, California).

Wheelchair Maneuverability: Turning space: 60-inch diameter or 60×60 T-space (Texas, implicitly supported by others).

Door Hardware: Operable without grasping, pinching, or twisting (Florida, California).

Accessibility Emphasis: Clear floor space and accessible pathways/fixtures for wheelchair users (all).

ADA Swing Clear Hinges with Various Applications

Waterson ADA swing clear hinges meet all the requirements, featuring speed control for ADA recessed door clearance of more than 32″ and exceptional durability. As a result, the innovative spring door closers provide exceptional functionality with aesthetics and achieve many ADA Compliance Standards. With an ADA-compliant 5 lbs opening force, adjustable speed control, a closing time of over 5 seconds, a sleek design, and various PVD finish options, this ADA operating hardware is a top choice for accessible doors.

The ADA swing clear hinges design was awarded by Red Dot Design Award as the Red Dot Winner – Product Design. In 2023, they achieved iF Product Design Winner and Taiwan Excellence Award in 2024.

Besides, our butt hinges also provide ADA compliance to commercial, office, and residential spaces. Explore Waterson ADA Door Hinges Applications here:

ADA Compliance and More

Waterson not only provides ADA-compliant self-closing hinges for commercial use but can also provide back-to-back ADA door handles to solve possible installation and aesthetic problems. Waterson products are designed and manufactured by skilled technicians who can customize specific needs into each design.



Waterson ADA Commercial Door Hinges

Waterson ADA Swing Clear Hinge combines an overhead closer and hinge into one attractive component with optional hold-open and door stop features. These hinges are ideal for commercial openings, gates, and glass doors. These hinges are easily installed and adjusted to comply with ADA & ICC A117.1 requirements for opening force and to assure quiet, secure closing. Made with stainless steel, Waterson closer hinges meet NFPA 80 and are UL 3-hour fire-rated, as well as being one of the best door hinges for both interior and all-weather exterior openings. See all our features.

Request For Quote

Please note that Waterson closer hinges start from a size of 4″x4″. If you’re in need of smaller self-closing hinges, we’d recommend checking out some other resources! Also, we only provide single acting closer hinges. Thank you.
